| Brand Name : | YXFiber |
| Model Number : | YXF-GE |
| Certification : | CE RoHS FCC |
| Price : | $4-$40/PCS |
| Payment Terms : | T/T, L/C, Western Union |
| Supply Ability : | 100000pcs per month |
| Delivery Time : | 1~3working days after payment |
Features:
1. 1.25G- BIDI SFP 3km, 10km, 20km, 40KM,60km, 80km,100km, 120km etc LC connector
2. Dual data-rate of 1.25Gbps operation
3. 1310nm/1490nm FP laser and PIN photo detector
4. 1550nm FP laser and PIN photo detector
5. BIDI LC/UPC type pluggable optical interface
6. Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
7. RoHS compliant and lead-free
8. Single +3.3V power supply
9. Support Digital Diagnostic Monitoring interface
10. Case operating temperature Commercial: 0°C to +70°C
Advantages:
1. The transceiver is a low power, high performance, cost effective module supporting data-rate up to 1.25Gbps Max 80km transmission distance.
2. The low jitter and high sensitivity are extinguished advantages with DFB LD and PIN receiver.
3. The transceiver incorporates TX_DIS control, TX-FAULT and RX_LOS monitor functions. The devices are Class I laser safety compliant.
Specifications:
| Technical Parameters | Descriptions | Technical Parameters | Descriptions |
| Model Number | YXF-GE | Interface | LC |
| Fiber type | SMF | Laser/Detector | FP/PIN DFB/PIN |
| Form Factor | BIDI SFP | DDM | Yes |
| Data Rate | 1.25Gbps | Certificate | CE,ROHS,FCC,ISO9001,SGS |
| Wavelength | 1310/1550nm, 1490/1550nm | Power Supply | 3.3V |
| Distance | from 3km to 120km | Temperature | 0~70°C |

|
